CollarEV: Pioneering Green Mobility in India
CollarEV is an innovative initiative spearheaded by Pepfuels, with substantial funding and support from the Oil and Natural Gas Corporation (ONGC). This collaboration is dedicated to fostering clean and sustainable transportation solutions in India, targeting both urban and rural areas to reduce the nation's carbon footprint. support from the Oil and Natural Gas Corporation (ONGC). This collaboration is dedicated to fostering clean and sustainable transportation solutions in India, targeting both urban and rural areas to reduce the nation's carbon footprint.
CollarEV's mission is to promote the widespread adoption of electric vehicles (EVs) and other eco-friendly transportation methods. The initiative aims to create a greener, more sustainable future by reducing dependency on fossil fuels and minimizing environmental pollution. The vision is to position India as a global leader in green mobility through advanced technological solutions and robust infrastructure.
CollarEV's efforts align with ONGC's renewed focus on environmental responsibility. By promoting the adoption of EVs and other green technologies, CollarEV aims to significantly reduce greenhouse gas emissions, decrease air pollution, and contribute to a healthier and more sustainable environment.
CollarEV is poised to play a crucial role in shaping the future of transportation in India. With continuous support from ONGC and a commitment to innovation, the initiative aims to expand its reach, enhance its services, and make green mobility accessible to all. By doing so, CollarEV envisions a cleaner, more sustainable India where environmentally friendly transportation is the norm rather than the exception.
IDC Range
Top Speed
Kerb Weight
Charging
Battery capacity
Peak Power
170 Km
50 kmph
77 Kg
2hr 30min
2.7 kwh
2.2 kw
Upgrade it to 8 years / 1 00 000 km with collerev
Capacity
31Ah / 1.5kWh*
Cells
Premium 18650 lithium cells
Features
Easily removable, can be charged when installed in bike or separately. Smart charging system. Integrated SoC indicator. Intelligent battery management system with CAN for increased safety and performance optimization.
Voltage (nominal)
48V
EBS - Electronic Braking System to regenerate the braking power into the battery and increase range. Enable regenerate in the CAKE Connect app.
Disc
Stainless steel, 220mm diameter
Type
Motorcycle brake system, two piston calipers. Hand levers for both front- and rear brake.
0-100%
3 hours*
0-80%
2 hours*
Type
10A external charger for standard 220V outlets
Features
High efficiency FOC controller
Features
TFT display with battery SoC, speedometer, odometer, ride mode selection and telltales.
Fork angle
25°
Ground clearance
260mm / 10.24''
Height to handle
1035mm / 40.7"
Offset
21.7mm / 7/8''
Seat height
790mm / 31.1'' (seat adjustment +- 85mm / 3.3")
Trail
78.1mm / 3.1''
Wheel base
1210mm / 47.5''
Width
750mm / 29.5"
Electric motor
Interior permanent magnet motor
Nominal power
1.55 KW
Peak power
2.8 kW*
Torque (wheel)
60Nm*
Type
Direct drive (hub motor)
Material
PC/ABS plastic
Build
6061 aluminum, extruded, forged, machined, welded and painted.
Travel
90mm / 3.54"
Type
Single crown, RWU spring fork
Interface
31.8mm / 1.25"
Material
Aerospace grade 7050 aluminium
Rise
117.5mm / 4.63"
Width
695mm / 27.36"
Travel
120mm / 4.72"
Type
260mm / 10.24" shock with adjustable pre-load
Classification
L1e-b*
License
AM, B*
2 different ride modes for extended range or balanced performance
Range
Mixed city riding (WMTC-II): 54km*
Top speed
45km/h*
Battery
11kg / 24.2 lbs
Dry
59kg / 130lbs
Max. permittable load
245kg / 540 lbs (bike + battery + rider + passenger + carry-on items)
Hubs
Forged and CNC aluminium Cake hubs
Rims
14"x2.15" lightweight motorcycle rims
Tires
14"x3.00" motorcycle tires
*Disclaimers
The street legal bikes are homologated for the specific country the bike is delivered to. That means that lights, blinkers and other "street legal necessities" might differ in look, style and dimensions, everything to meet the local regulations. Accordingly, details might look different from the product photo. • Images show fully specced vehicles. • The specs, such as range, speed and power are not estimated by CAKE. The numbers are the result from the European homologation test, WMTC-II. (performed in a controlled environment and might differ from regular use) • Peak power is the maximum power the power supply can sustain for a short time. • The actual energy storage capabilities of the battery can vary from the nominal rated capacity. • Torque values based on motor specifications. • Charging time may differ depending on the voltage in the local grid. • All specifications are subject to change without notice. • It is the buyer’s/owner’s responsibility to ensure all local rules, regulations, classifications and license requirements are followed.
