1. Enhanced Acceleration (Quick Start & Smooth Power Delivery)
2. Superior Hill Climbing & Load Handling
3. Manoeuvrability & Traction Control
4. Provide Off Road Adventure and Sporty Performance
1. Minimalistic Design focusing on simplicity, performance and efficiency.
2. Lightweight Construction contribute to rapid acceleration & nimble handling.
3. Perfect blend of aesthetics and functionality, provide a swift, agile and enjoyable ride.
1. Extended Range for Daily use
2. Multiple Trips in a day – 90 km+ range
Scenario 1 – Daily Commute
Home to Work: 15 km one way
Total Daily Commute: 30 km
Days on One Charge: 3 days
Scenario 2: Errands & Social Visits
Errands: 10 Km
Social Visits: 15 Km
Additional Trips: 10 Km
Total Daily Usage: 35 Km
Days on One Charge: 2.5 Days
1. Extended Battery Life & Mileage Potential: Proving 1000 to 1300 number of charging cycles which provide
a travel distance of around 117,000 Km.
2. Consistence Performance
Capacity
31Ah / 1.5kWh*
Cells
Premium 18650 lithium cells
Features
Easily removable, can be charged when installed in bike or separately. Smart charging system. Integrated SoC indicator. Intelligent battery management system with CAN for increased safety and performance optimization.
Voltage (nominal)
48V
EBS - Electronic Braking System to regenerate the braking power into the battery and increase range. Enable regenerate in the CAKE Connect app.
Disc
Stainless steel, 220mm diameter
Type
Motorcycle brake system, two piston calipers. Hand levers for both front- and rear brake.
0-100%
3 hours*
0-80%
2 hours*
Type
10A external charger for standard 220V outlets
Features
High efficiency FOC controller
Features
TFT display with battery SoC, speedometer, odometer, ride mode selection and telltales.
Fork angle
25°
Ground clearance
260mm / 10.24''
Height to handle
1035mm / 40.7"
Offset
21.7mm / 7/8''
Seat height
790mm / 31.1'' (seat adjustment +- 85mm / 3.3")
Trail
78.1mm / 3.1''
Wheel base
1210mm / 47.5''
Width
750mm / 29.5"
Electric motor
Interior permanent magnet motor
Nominal power
1.55 KW
Peak power
2.8 kW*
Torque (wheel)
60Nm*
Type
Direct drive (hub motor)
Material
PC/ABS plastic
Build
6061 aluminum, extruded, forged, machined, welded and painted.
Travel
90mm / 3.54"
Type
Single crown, RWU spring fork
Interface
31.8mm / 1.25"
Material
Aerospace grade 7050 aluminium
Rise
117.5mm / 4.63"
Width
695mm / 27.36"
Travel
120mm / 4.72"
Type
260mm / 10.24" shock with adjustable pre-load
Classification
L1e-b*
License
AM, B*
2 different ride modes for extended range or balanced performance
Range
Mixed city riding (WMTC-II): 54km*
Top speed
45km/h*
Battery
11kg / 24.2 lbs
Dry
59kg / 130lbs
Max. permittable load
245kg / 540 lbs (bike + battery + rider + passenger + carry-on items)
Hubs
Forged and CNC aluminium Cake hubs
Rims
14"x2.15" lightweight motorcycle rims
Tires
14"x3.00" motorcycle tires
*Disclaimers
The street legal bikes are homologated for the specific country the bike is delivered to. That means that lights, blinkers and other "street legal necessities" might differ in look, style and dimensions, everything to meet the local regulations. Accordingly, details might look different from the product photo. • Images show fully specced vehicles. • The specs, such as range, speed and power are not estimated by CAKE. The numbers are the result from the European homologation test, WMTC-II. (performed in a controlled environment and might differ from regular use) • Peak power is the maximum power the power supply can sustain for a short time. • The actual energy storage capabilities of the battery can vary from the nominal rated capacity. • Torque values based on motor specifications. • Charging time may differ depending on the voltage in the local grid. • All specifications are subject to change without notice. • It is the buyer’s/owner’s responsibility to ensure all local rules, regulations, classifications and license requirements are followed.
